Styrofoam Router Machine
★ Features:
1. Imported large cross-section linear guide rail, free maintenance self-lubricating for whole life span.
2. BT40 clapting big tool electric spindle with highest speed 18000RPM.
3. Overall EPC workbench, through the strict annealing heat treatment process,etc.,to ensure the stability and
rigid structure of the bed.
4.Taiwan LNC control system,safe and reliable operation, fast and efficient code reading,online simulating
function and online monitoring function,ensuring the efficiency and security of processing.
★ Description & Specifications:
|
X Working area |
2000mm (optional 2500mm) |
|
Y Working area |
4000mm (optional 4500mm、5000mm) |
|
Z Working area |
1000mm |
|
|
2000*4000mm(other can be optional) |
|
Table structure |
CX250 inblock cast |
|
X,Y,Z structure |
X,Y gear wheel, Z ball screw |
|
Max Rapid Travel Speed |
16000mm/min |
|
Max Working Speed |
10000mm/min |
|
Spindle power |
7.5KW water cooling |
|
Max speed |
18000r/min |
|
Taper bore |
ISO40(Max. ￠32mm) |
Sample Show
