XL1325 ATC Cnc wood Drilling Machines

Features

● High-performance all-round machinery with extraordinary value, but at a very economical price. With linear tool changer, constructed with world-class components, consistent high performance.
● Featuring Italian high frequency air-cooling electronic spindle and world-class servo motor and driving system.
● Vacuum table using high-density (1.3-1.45g/cm) material with great suction strength, comfortably accommodating all sizes of work piece.
● Syntec controller—enabling this product to accomplish multi-layer 3D job, cutting, engraving, milling, all at ease.

★Paramter

X Working Area	1300mm
Y Working Area	2500mm
Z Working Area	380mm
Table size	1300x2500mm
Traveling Positioning Accuracy	±0.05mm
Repositioning Positioning Accuracy	±0.05mm
Table Surface	By suction
X,Y ,Z Structure	XY gear wheel, Z ball screw
Max. Power Consumption(Without spindle)	2.8KW
Max. Rapid Travel Rate	50000mm/min
Max. Working Speed	25000mm/min
Spindle Power Motor	9 KW
Spindle Speed	0-24000r/min
Drive System	Japan Servo motor and driver
Working voltage	AC380V/60Hz
Command	G-code

APPLICATIONS
● Furniture: ideally suitable for processing cabinet door, wooden door, solid wood furniture, panel wood furniture, windows, tables and chairs, etc.
● Other wooden products: stereo box, computer desk, musical instruments, etc.
● Well-suited for processing panel, insulating materials, plastic, epoxy resin, carbon mixed compound, etc.

APPLICABLE MATERIALS
acrylic,density boar,wood ,plaster,organic glass,stone,artificial stone,graphite,PVC,EPS, soft metals like aluminum and copper and other non-metal carbon mixed compound,etc.

Samples:
