XLM25-2 wood cnc router machine

Furniture Industry: Panel Furniture, Office Furniture, Wood Door, Cabinet, etc;Wood-working Industry: Musical Instrument, Kitchen Doors, Windows, etc;Suitable Material: Wood, Solid Wood, Panel, Acrylic, Plexiglass, MDF, Plastic, Copper, Aluminum, etc.
FEATURES
● Independent and Simultaneous Working of the Heads
● U-Steel Lathe Bed and Gantry—Stable
● 3.0 KW HSD Air-Cooling Spindle
● THK Linear Rails—Dustproof and Self-Lubricating
● Rack Pinion Transmission

Parameter

X Working Area	1300mm
Y Working Area	2500mm
Z Working Area	200mm
Traveling Positioning Accuracy	±0.05mm
Repositioning Positioning Accuracy	±0.05mm
Table Surface	Vacuum table
X,Y ,Z Structure	XY gear wheel, Z ball screw
Max. Power Consumption(Without spindle)	1.84KW
Max. Rapid Travel Rate	25000mm/min
Max. Working Speed	15000mm/min
Spindle Power Motor	4.5KWx2，air cooling spindle
Spindle Speed	0-24000r/min
Drive Motor	Servo motor
Driver	Servo motor driver
Command	G-code.u00.mmg*.plt
Working voltage	AC220V/50Hz AC380V /50HZ
Control System	NC Studio
Guide rail	25 Square rail (TAIWAN BRAND:TBI)
Control cabinet	Independent cabinet

★ Application:

Mainly used for wood furniture industry like processing wood door,cabinet door, art and craft
door, MDF cutting, wood board cutting and processing other nonmetal materials, etc.

Samples :
