XL 1313 advertisement cnc router machine

XL 1313 advertisement cnc router machine

Advertisement cnc router machine, as its name ,this machine mainly uses in advertise industrial, cutting labels,cutting acrylic signs,PVC signs, LED light letters,wood letters ,cnc router

keywords：

cnc routers 4 axis cnc routers wood cnc routers cnc machines advertising cnc routers jinan cnc routers cnc routers china

E-mail：

xlcncrouter@gmail.com

Message

XL 1313 advertisement cnc router machine

Advertising CNC Router is a computer controlled designing machine used to cut hard materials. We manufacture these superior quality CNC Router machine in compliance with the ISO set standards. These machines are widely appreciated for their efficient lubricating system, less power consumption and rigid construction. Our machine is commonly used for the engraving and cutting labels, number plates, languages and graphics on gifts and souvenirs.

Features:

· Whole machine is welded with seamless steel structure, the stability is excellent, not easy to be deformed.

· Three axes Adopt Germanyrolling ball screw and linear orbit, stable working , high precision and longevity.

· Well compatibility: CAD/CAM designing software e.g. Type 3/Artcam/Castmate/Wentai etc.

· X axis is dustproof; It makes sure the steady working performance of the machine for long-term using.

· Has the function of re-carving after break point and power failure.

· Perfect lubricating system makes maintenance much easier.

· High precision, the curving and linear speeds are consistent. Adopting excellent parts makes the fault rate to be the lowest one.

· Adopting water cooling system, it can provide good cooling effect when carving flinty materials.

Parameter

model	1313	1318	1325
X working area	>1200mm	>1200mm	>1200mm
Y working area	>1300 mm	>1800mm	>2400mm
Z working area	100mm	100mm	80mm
table size	1400mm*1680mm	1400mm*2280mm	1400mm*2880mm
traveling positioning accuracy	0.05mm	0.05mm	0.05mm
repositioning positioning accuracy	0.02mm	0.02mm	0.02mm
table structure	aluminum	aluminum	aluminum
X,Y,Z structure	X,Y,Z ball screw	X,Y,Z ball screw	X,Y,Z ball screw
max.power consumption(without spindle)	0.8kw	0.8kw	0.8kw
max.rapid travel rate	10000mm/min	6000mm/min	6000mm/min
max.working speed	3000mm/min	3000mm/min	3000mm/min
spindle power motor	1.5kw	1.5kw	1.5kw
spindle speed	0-24000r/min	0-24000r/min	0-24000r/min
drive system	stepper	stepper	stepper
working voltage	AC220V/50HZ	AC220V/50HZ	AC220V/50HZ
command language	G code	G code	G code
operating system	DSP controlling	DSP controlling	DSP controlling

Applicable Industries:

· Advertisement: engraving and cutting various labels, number plate and etc.

· Art craft: engraving characters of any languages and graphics on gifts and souvenirs.

Applicable Materials:

· PVC, acrylic, density board, wood, crystal board and so on.

Processing Effect:

· Our router may carve various kinds of relief, shadow, craft and gift such as the following pictures
